process parameters :

● apply to lcd size for a 5-inch stn / cstn / tft-lcds (platform can be expanded to 7 inches);

● panel thickness: 0.3 ~ 1.1mm;

● pressing the fpc range: 6 ~~ 80mm;

● pitch value of more than 60μm, the actual accuracy of ± 8μm;

● pressure head specifications: 60 * 1.2mm, according to customer requirements change;

● two head center distance 300mm;

● temperature range: rt-400 ° c;

● heating: temperature control;

● process cycle: 22 seconds / slice.

average production can 260pcs / hour or more; ● air consumption: 0.4 cubic meters / minute;

● working pressure 0.4 ~ 0.6mpa;

● power: 220v, 50hz, 800w;

● total weight: 150kg dimension: l800 * w840 * h1310 (720)
