process parameters:

● apply to lcd size for a 5-inch stn / cstn / tft-lcds (platform can be expanded to 7 inches);

● the minimum distance of ic and glass 0.5mm;

● pressure head specifications: 30 * 5.0mm, according to customer requirements of production;

● the actual accuracy: ± 3μm, ??pitch value 16μ

● two-head center distance: 380mm;

● temperature range: rt-400 ° c;

● heating: temperature control;

● process cycle: 10 seconds / slice. average capacity 680pcs / hour;

● air consumption: 0.4 cubic meters / minute;

● working pressure 0.4 ~ 0.6mpa;

● power supply: single phase 220v, 50hz, power 1000w;

● total weight: 180kg dimension: l890 * w840 * h1310 (720)
