process parameters

●applicable to lcd size for a 5-inch stn / cstn / tft-lcds (platform can be expanded to 7 inches);

●the minimum distance of ic and glass 0.5mm;

pressure head specifications: 30 * 5.0mm, according to customer requirements of production;

●the actual accuracy: ± 3μm,pitch value 16μ

●the three head center distance: 280mm;

●temperature range: rt-400 ° c;

●heating: temperature control;

●process cycle: 10 seconds / slice. actual capacity 900pcs / hour;

●air consumption: 0.6 cubic meters / minute;

●working pressure 0.4 ~ 0.6mpa;

●power supply: single phase 220v, 50hz, power 1500w;

total weight: 220kg dimension: l890 * w840 * h1360 (720)
