process parameters

●apply to lcd size for a 5-inch stn / cstn / tft-lcds (platform can be expanded to 7 inches);

●panel thickness: 0.3 ~ 1.1mm;

●ic size: min 3.0 * 0.6mm, max 30 * 5.0mm thickness 0.3 ~ 1.0mm

●the minimum distance of the ic glass 0.5mm;

●ic disk size 2/3/4inch the the 2 inch can put 16 inch put 12 put 8 in, 4-inch;

pressure head specifications: 18 * 2.0mm, according to the customer requirements change;

●bonding ic varieties: the same kind of ic;

●the actual accuracy: ± 3μm;

●temperature range: rt-400 ° c;

●heating methods: thermostatically controlled

●process cycle: 3.5 seconds.

actual production can 900pcs / hour or more; ●air consumption: 0.4 cubic meters / minute;

●working pressure 0.4 ~ 0.6mpa;

●power supply: single phase 220v, 50hz, power 1200w;

total weight: 250kg dimension: l1000 * w1070 * h1450 (770)
